Pesticide production line (Jiangsu Yangnong Chemical Co., Ltd.)
Application client:Jiangsu Yangnong Chemical Co., Ltd.Selected products::Flash dryer, vacuum rake dryer
Materiel:: Pesticide
Detailed description
Material overview:
Pesticides, currently the world's unified English name is pesticide-that is, "killing agents", but in fact, the so-called pesticides refer to the prevention and control of harmful organisms (pests, mites, nematodes, pathogens, miscellaneous bacteria Grass and rats. Later, through a longer-term development of production and life processes, I gradually realized that some naturally have the ability to prevent and control harmful organisms in agriculture and animal husbandry. To 17 categories, etc.) and regulate plant growth of chemicals and biological drugs. Various additives used for hygiene and improving the physical and chemical properties of active ingredients are usually included.
product description:
The machine adopts interlayer heating and internal stirring at the same time, with large heat transfer surface and high thermal efficiency. The machine is equipped with stirring to form a continuous circulation state of the materials in the barrel, which further improves the uniformity of the materials heated. The machine is equipped with stirring, so that the slurry, paste and paste materials can be dried smoothly.
Application:
● The following materials are dried in pharmaceutical, food, chemical and other industries.
● Suitable for paste, paste and powder materials.
● Heat sensitive materials that require low temperature and dry.
● Easily oxidized, explosive, strongly irritating and highly toxic materials.
● Materials requiring recovery of organic solvents.
Technical Data Sheet:
project | Type | |||||||||
name | unit | ZB-500 | ZB-750 | ZB-1000 | ZB-1500 | ZB-2000 | ZB-3000 | ZB-4000 | ZB-5000 | ZB-6000 |
Working volume | L | 300 | 450 | 600 | 900 | 1200 | 1800 | 2400 | 3000 | 3600 |
Heating area | m2 | 3.2 | 4.4 | 5.1 | 6.3 | 8.1 | 10.6 | 12.3 | 14.2 | 16.5 |
Stirring speed | rpm | 8 ~ 18 | ||||||||
power | Kw | 4 | 5.5 | 5.5 | 7.5 | 7.5 | 11 | 15 | 18.5 | twenty two |
Sandwich design pressure | Mpa | 0.3 | ||||||||
Pressure in the cylinder | Mpa | -0.092 ~ -0.096 | ||||||||
Note: The evaporation of water is related to the characteristics of the material and the drying temperature. As the product is continuously updated, the relevant parameters are changed without prior notice. |
Pictures taken on site:
